Sky Italia relied on Imagine solutions to seamlessly integrate SDI and IP workflows across multiple locations in its facility.
Customer profile
Sky Italia is the largest pay-TV operator in Italy and one of the largest in Europe, serving 4.73 million subscribers. The company distributes more than 150 channels, mainly via satellite, and its Sky Go brand of content is distributed to mobiles and tablets using OTT delivery. Sky Italia is owned by Sky, Europe’s leading entertainment company, serving more than 21 million customers across five countries: Italy, Germany, Austria, the UK and Ireland.
When Sky (formerly BSkyB) acquired Sky Italia in 2014 and Sky Deutschland in 2015, the multinational, UK-headquartered PayTV giant decided to consolidate the new markets’ operations in Milan, tasking Sky Italia with handling all signal contribution for Sky Deutschland.
Sky Italia supports more than 150 of its own channels from operations centers in Milan and Rome, where individual feeds and multiplexed streams are transported within and between the two locations. Faced with the additional burden of handling signal contribution between Milan and Munich, Sky Italia needed to migrate to a large-scale routing system.
As the new routing system needed to be distributed across several locations (floors) within the Milan facility, Sky Italia decided to design the system around an IP switching core using commercial off-the-shelf (COTS) IP switches.
However, they also wanted the new implementation to connect to the legacy SDI systems within the Milan facility.
The immediate goal was to leverage the speed and scalability benefits of IP, while achieving the same level of switching quality as they had experienced using a baseband router. In addition, Sky Italia planned to implement an IP-based disaster recovery system at their Rome location. In the longer term, as more production and broadcast equipment becomes IP-centric, Sky Italia’s plan is for all the video distribution components within their Milan facility to be IP-based, creating a fully virtualized audio/video routing ecosystem. They were ready to begin a managed transition to an all-IP infrastructure that minimizes disruption and preserves their existing workflows.
Key to Sky Italia’s choice of a new system was their preference for a unified, open and standards-based approach. They were also looking to deploy a highly reliable and scalable solution to support their current business, as well as continued expansion. And because they were heading down a new technology path, they wanted to partner with a vendor that shared their vision.Sky Italia ultimately chose a state-of-the-art solution featuring Imagine Communications’ Platinum™ IP3 routers and high-performance Arista network switches, with the entire workflow managed by Imagine’s Magellan™ SDN Orchestrator.
Deployed in fully redundant 1+1 configurations, the IP3 routers are used to switch the SDI signals, while the Arista IP switches, also in 1+1 redundant configurations, switch the IP-encapsulated SDI streams.
The IP3 routers feature integrated Platinum Uncompressed-over-IP (UCIP) modules, which encapsulate and de-encapsulate signals and move them between the SDI domain and the IP domain. In total, the first phase of Sky Italia’s new system can handle 640×640 IP streams in a main and backup network, connecting to a 128×128 SDI matrix in a non-blocking way.
Also key to Sky Italia’s implementation is Imagine’s Selenio™ MCP processing, compression and IP networking platform, featuring 500 multichannel UCIP gateway cards. Both the Platinum and Selenio UCIP cards are modular “on-ramp/off-ramp” solutions that encapsulate SDI baseband signals into IP streams and vice versa. Sky Italia can use the UCIP modules to manage the synchronization of IP signals where they re-enter the HD-SDI world, eliminating network jitter and aligning perfectly to legacy sync signals. The modules are also able to synchronize its output time-base via PTP (SMPTE 2059), and can do full AES67 audio breakaway and re-combination of the audio signals from/to the SDI signals.
The Magellan SDN Orchestrator controls the Platinum IP3 routers, i.e., the SDI signal flows within the Sky Italia infrastructure. Sky Italia can also use the Magellan SDN Orchestrator to control the stream-flows and mappings inside their IP network — providing the bandwidth management and Quality of Service (QoS) required to achieve professional broadcast performance. SDI and IP sources and destinations are kept in a single Magellan SDN Orchestrator database, and the gateways between the SDI infrastructure and the IP virtual matrix — as well as the allocation of bandwidth between the IP switches — are managed using tie-line control methods.
The Sky Italia system is a hybrid SDI and IP matrix distributed across several areas of one building – all controlled by a seamless, unified management layer.
The result
Taking a visionary but realistic approach to their IP transition plans, Sky Italia chose to implement an open-standard, interoperable system that allows them to make a measured investment in IP, while keeping intact the already paid for infrastructure that handles SDI signals. The company realized that it was not practical to have their operators deal with the baseband network in one way and with the IP network in a completely different way — they needed to have the same operational interfaces and processes in both networks. With advanced techniques that transparently map IP signals into the existing workflow, the Magellan SDN Orchestrator provides a seamless, unifying management layer for both the Platinum routers and the IP switches. This allows Sky Italia operators to use familiar hardware and software control panels to accommodate both signal types in the hybrid workflow environment. As the interplay between the SDI infrastructure and IP-based connectivity is managed using tie-line control methods, the upstream functions in Sky Italia’s plant — automation, tally systems, multiviewers, and master control switchers — can continue to use existing industry-common routing control protocols, even when the source, destination, or both are actually in the IP domain.
The result is a network based on COTS IP switches that provides the same real-time quality performance that baseband systems deliver today. Because Imagine offers two versions of its UCIP modules — one for the high-density Selenio media convergence platform and one to be installed directly in the Platinum IP3 frame — Sky Italia was able to design an exceptionally compact solution that is capable of handling a large number of streams and can be distributed across multiple rooms using IP connectivity. Overall, this hybrid system has enabled Sky Italia to leverage the advantages of IP technology without disrupting their established operational procedures and without sacrificing any of the performance parameters required in a broadcast operation, as well as buy time for their operational staff to adjust to new, all IP-based workflows.
“Our technology vision at Sky Italia is forward-looking, but also pragmatic. The end goal is an all-IP infrastructure, but we want to maintain our existing SDI system until we get there. Imagine’s proven, open-standard technology supports our vision, and they have more than demonstrated their competence in the IP space.”
